Laboratory Vacuum Oven

“TEMPO” make vacuum oven are designed & manufactured to comply with the requirements of the industry. It is widely applicable for drying & sterilization in fields of biochemistry, pharmacy, medicine, health, agriculture & scientific research and environment protection. It is designed especially for the drying of material which is thermos ‐ sensitive or decompounded and oxidative easily.

Standard Models
Inside SS 304 with mirror polish & outer made from mild steel (CRCA) with powder coated.

GMP Models
Inside SS 316 with mirror finish and outside made from SS 304 with the dull buff finish.

Construction
“TEMPO” make vacuum oven is made of stainless steel (SS 304) inner and thick gauge mild steel (CRCA) sheet duly epoxy powder coated outer body. 4” high grade glass wool insulation for rectangular model & 3” high grade glass wool insulation for the circular model to minimized heat loss. Shelf system stainless steel trays improve heat conduction to samples.

Technical Specification

• Controlling System : Microprocessor based autotune PID temperature controller with a dual display of set value & process value for precise control of temperature.
• Heating System : Heating element made from best quality Kanthal DSD wire is used to develop unique temperature inside the chamber.
• Insulation : 4” high grade glass wool insulation for rectangular model & 3” high grade glass wool insulation for the circular model to minimized heat loss.

Features

• The toughened glass window in the door to allow viewing of samples inside the chamber.
• Secure door latch & silicon gasket on the vacuum chamber to tight seal & maintain leak rate less than 1Hg. per 24 hour period.
• Specially designed stainless steel rod trays ensure uniform temperature distribution.

Safety Features
Safety cum standby thermostat to cut off the heater supply in case of overshoot of temperature.

Optional Features

• Data logger
• CFR 21 part 11 compliance software for data logger
• Safety digital temperature controller
• Timer
