Laboratory Refrigerators

“TEMPO” make glass door refrigerators are stable and reliable with the refrigerated environment for exact laboratory requirements. Lab refrigerators are used for maintaining storage conditions of a product, to prevent its exposure to low temperature applications, where the temperature requirements are on the lower side. Ideal temperature environment for clinical research, pharmaceutical and industrial use. Adjustable shelves and wide range set point for varying laboratory applications including chromatography and pharmaceutical storage. The application includes refrigerated storage of vaccines, reagents, cultures, medicines and blood samples.

Standard Models
Inside SS 304 with mirror polish & outside mild steel powder coated.

GMP Models
Inside SS 316 with mirror polish & outside stainless steel 304 with the dull buff finish.

Construction
“TEMPO” make glass door refrigerators are made of double walled and triple at backside construction. Front door multi glass fitted in mild steel powder coated or SS 304 with full-length magnetic gasket for proper sealing with lock and key. Full view inner acrylic door. The motorized blower is fitted on the back side for uniform temperature even under loaded conditions. 3” thick PUF insulation. The unit is provided with adjustable stainless steel rod trays. The equipment is mounted on caster wheels for easy movement.

Technical Specification

• Controlling System : Microprocessor based auto tune PID temperature controller with a dual display of set value & process value for precise control of temperature.
• Sensor : PT 100 sensor is used for temperature & electronic type sensor for humidity.
• Heating System : High quality SS tubular heaters are used for better heating.
• Refrigeration System : CFC Free hermetically sealed Emerson Copeland make compressor for better cooling with R134 A (Eco Friendly) refrigerant with a time delay to safeguard compressor system.

Features

• Full view observation acrylic door with a gasket to observe the sample inside the chamber. Interior illumination for working area.
• Specially designed stainless steel rod trays ensure uniform temperature distribution.

Safety Features

• Safety standby thermostat to cut off heater supply in case of overshoot of temperature.
• Safety audio visual alarms for temperature overshoot & undershoot.
• Compressor ON delay timer (2 min) to safe guard the compressor.

Optional Features

• PLC for auto change over for standby refrigeration system
• CFR 21 part 11 compliance software for PLC with RS 485 or ethernet communication
• Stand by refrigeration
• Data logger
• CFR 21 part 11 compliance software for data logger
• Data scanner complete with sensor
• SMS mobile alert system
• Door access security system
• Safety digital temperature controller
• Timer

“TEMPO” lab refrigerator is made of double walled construction with thick high grade PUF insulation. Full view inner acrylic door & front door with gasket & locking arrangement. The motorized blower at the backside of the chamber develops a unique airflow system to maintain uniform temperature condition inside the chamber. Unique airflow assures quick recovery after door openings. The unit is provided with a user friendly adjustable specially designed S.S rod trays, ensures uniform temperature distribution. The equipment is mounted on castor wheels for easy movement.

Standard Models
Inside S.S. 304 with mirror polish & Outside mild steel powder coated.

GMP Models
Inside S.S. 316 with mirror polish & Outside stainless steel 304 with the dull buff finish.

Construction
Lab refrigerator is made of double walled construction with thick high grade PUF insulation. Full view inner acrylic door & front door with gasket & locking arrangement. The motorized blower at the backside of the chamber develops a unique air ow system to maintain uniform temperature condition inside the chamber. Unique air ow assures quick recovery after door openings. The unit is provided with a user friendly adjustable specially designed S.S rod trays, ensures uniform temperature distribution. The equipment is mounted on castor wheels for easy movement.

Technical Specification

• Controlling System : By means of imported microprocessor based auto tuned PID controller with CE mark & dual display of set value & process value.
• Sensor : PT 100 sensor is used for sensing the temperature.
• Heating System : High quality S.S. tubular heaters are used for better heating.
• Refrigeration System : CFC free hermetically sealed Emerson Copeland make compressor for better cooling with R134 A (eco-riendly) refrigerant with a time delay to safeguard compressor system.
• Validation Port : 50 mm validation porthole with silicon rubber seal to insert sensor for validation

Features
Full view observation Acrylic door with a gasket to observe the sample inside the chamber. Interior illumination for working area. Specially designed stainless steel rod trays ensure uniform temperature distribution.

Safety Features
Safety standby thermostat to cut off heater supply in case of overshoot of temperature. Inbuilt overload protector provided for the hermetically sealed compressor. Compressor ON delay timer (2 min) to safeguard the compressor.

Optional Features

• PLC based control system
• Stand by the refrigeration system
• Ethernet / RS485 communication
• Data logger
• Data scanner complete with sensor
• SMS mobile alert system
• Door access security system
• Safety digital temperature controller
• Digital timer
• CFR 21 part 11 compliance software

When your testing requires a walk in rooms choose “TEMPO” controlled temperatures solution. Our test rooms feature automated process control, energy efficiency and a vast range of other features and options. Every “TEMPO” environmental room features equipment that reliably produces required conditions, structural integrity that keeps the room working properly through years of demanding test cycles, and measuring/monitoring equipment that precisely records all test data.

Standard Models
Inside S.S. 304 with mirror polish & outside mild steel powder coated.

GMP Models
Inside S.S. 316 with mirror polish & outside stainless steel 304 with the dull buff finish.

Construction
Light weight sandwich panel. Double walled construction with backside triple wall. 3″ thick PUF insulation ensures stable temperature with a reduction in energy consumption. The motorized blower at the backside of the chamber for recirculation of air to develop a unique airflow system which ensures maximum uniform temperature condition inside the chamber. The unique airflow assures quick recovery after door openings.

Single-phase, TEFC, F class insulation 1440 rpm, 230V. HIgh-quality SS tubular heaters are used for better heating. Steam injection system and reservoir tank with water level arrangement with indicator.

Technical Specification

• Control System : Microprocessor based PLC (up to 5000 readings) with 7″ touch screen colour HMI, which gives the direct display of process value and set the value of temperature and humidity inside the chamber. High speed ethernet based communication.
• Refrigeration System : The refrigeration is provided by means of CFC free hermetically sealed Emerson Copland compressor for better cooling with eco-friendly refrigerant.  The cooling system is made up of split type so as one can place the compressor coupled with condenser unit in a well ventilated area to avoid hot air throw in the stability room. The inbuilt stand by refrigeration system is provided with auto change over the facility.

Features

• Negligible maintenance – the sturdy design and long lasting finish ensures minimum maintenance for years.
• Minimal heat transfer – the tongue and groove edges of all panels are moulded to close tolerance ensuring a tight fit between panels. These prevent condensation from forming on the foam and minimize heat transfer.
• Quality accessories – hardware like hinges, handles etc. on panels from best indigenous suppliers.

Optional Features

• CFR 21 part 11 compliance software
• Standby refrigeration and humidity system
• Ethernet communication
• Door access system
• Data logger/scanner
• Touch screen HMI
• PLC-based control
• Email alert
• Mobile alert system
• Safety alarms
