Constant Temperature Water Bath

“TEMPO” make constant temperature water bath are ideal for application in refractometry, polarimetry, rotational viscometry, in biotechnology laboratories for the development of culture applications & general laboratory work. Besides it, these constant temperature water baths are useful in the chemical industry, biology, pharmacy, environmental protection, hygiene & disease control, academies and other science research and producing areas.

Standard Models

• Inside SS 304 with mirror polish & outside mild steel powder coated.

GMP Models

• Inside SS 316 with mirror polish & outside stainless steel 304 with the dull buff finish.

Construction

• Constant temperature water bath is double walled in construction. The units are insulated with high grade glass wool/PUF.

Technical Specification

Controlling System

• Two separate imported microprocessors based autotune PID controller with CE mark & dual display of set value & process value for precise control of temperature.

Heating System

SS tubular heaters (water immersion type) is used at the bottom for better heat distribution.

Water Circulation

The water circulation pump is provided for better uniformity of temperature instead of the stirrer. The side mounted circulating pump provides the minimum capacity of 15 ltr per min.

Features

• Inner SS argon welded one piece pot which avoids leakages. 2” thick insulation ensures stable temperature & reduce energy consumption.
• The circulation pump is provided for better uniformity of temperature instead of the stirrer. The side mounted circulating pump provides 15 ltr/min of capacity. The lid mounted on top is removable. The circulation pump is used for the drain (do not dry run the circulations pump).

Optional Features

• Safety digital temperature controller
• Timer
