Laboratory Deep Freezer -20C

“TEMPO” make deep freezer are designed to provide an ideal freezing environment for advanced medical and industrial applications and also suitable for research laboratories, blood bank, biological use includes preservation of plasma, blood components, vaccines, etc.

Standard Models
Inside S.S. 304 with mirror polish & outside mild steel powder coated.

GMP Models
Inside S.S. 316 with mirror polish & outside stainless steel 304 with the dull buff finish.

Construction
Double walled construction. 3” Thick PUF Insulation ensures stable temperature with reduced energy consumption.

Technical Specification

• Temperature Control : Temperature is controlled by means of imported microprocessor based autotuned PID controller with CE mark & dual display of set value & process value.
• Refrigeration System : Refrigeration by means of CFC free hermetically sealed Emerson Copland make compressor with R 134A for better cooling. Full view observation Glass/Acrylic door with a gasket to observe the sample inside the chamber. Specially designed stainless steel rod trays ensure uniform temperature distribution.

Features
Full view observation Acrylic door with a gasket to observe the sample inside the chamber. Specially designed stainless steel rod trays ensure uniform temperature distribution.

Safety Features
Inbuilt overload protector provided for the hermetically sealed compressor.

Optional Features

• PLC for auto change over for standby refrigeration system with HMI
• CFR 21 part 11 compliance software for PLC with RS 485 or ethernet communication
• Stand by refrigeration and humidity system
• Data logger
• CFR 21 part 11 compliance software for data logger
• Data scanner complete with sensor
• SMS mobile alert system
• Door access security system
• Safety digital temperature controller
• Timer
